B&G 2019 » H5000 SYSTEM

H5000 Instruments

H5000 Displays Instrument CPU

The 5-inch, sunlight viewable, The system is powered by a smart
Graphic colour screen with a highly Central Processing Unit (CPU) which
intuitive user interface is packed runs three levels of software, Hydra,
with sailing features including SailSteer, Start Line, Hercules and Performance to match
AIS display and Pilot status. The bonded glass display your sailing requirements.
gives zero condensation and enhanced contrast. 5-inch
monochrome, segmented Race display also available. H5000 CPU function levels
FUNCTIONS Hydra Hercules Performance
Graphic Display Features Race Display Features Performance Wind Filtering • • •
3D Motion corrected Wind support • •
• Start Line • High Contrast 5-inch Ground Wind Speed and Direction •
display
• SailSteer SOG as Boat Speed option • • •
• Visual target indicator Dynamic Boat Speed Damping • •
• AIS repeater Polar Table and functions • •
• Low power consumption
• Pilot status HV Display Context Switching mode • •
Start Line proximity, with Bow Positioning • • •
• WindPlot
16 Custom User Channels • • •
• Quick, context-based CALIBRATION
menus AutoCal routines, including True Wind correction • • •

• Bright colour display Advanced True Wind Speed correction • •
Boat Speed Linearity/Heel correction • •
Cubic Spline interpolation • • •
H5000 Graphic 000-11542-001
INTERFACING
H5000 Race 000-11543-001
Selectable NMEA0183 Input/Output • • •
H5000 Webserver browser based control • • •
HV Displays H-Link Communications • • • • •
GoFree websockets v2
HVision bonded glass displays provide SENSOR SUPPORT
ultra-clear instrumentation with zero Dual Boat Speed input • • • •
Dual Wind Sensors (switching on wind angle)
condensation risk. Designed to be installed on the mast Rotating Mast support for Wind Calculation • • •
in the sailor’s line-of-sight, HV Displays show almost any Port & Starboard Rudder inputs, with Toe-In •
information on the system. When paired with H5000 Advanced Linear channel types Set A Set A+B
Hercules or Performance CPUs HV Displays will auto- Dual Depth sensors • • • • • •
Network Loadcells
switch data based on point of sail or pre-start status. Getting
the crucial information in the right place at the right time.
Analogue Displays
10/10 HV Display 000-11087-001 B&G’s Analogue displays provide a
20/20 HV Display 000-11088-001 clear view of key data types in a classic
30/30 HV Display 000-11089-001 display, meeting the aesthetic demands
40/40 HV Display 000-11090-001 of classic yachts and providing instant
understanding of important data, like Wind Angle, at a glance.

Analogue Displays – all models See www.bandg.com
