SISTEMA RGBW E LUCE DINAMICA / RGBW AND TUNABLE WHITE (TW) SYSTEM

Quick Color Control System

[ IP20 SELV ]
QCC-PLT 300

Modello / Model QCC-PLT 300
Alimentazione / Power supply 10-30 Vdc
Potenza / Power consumption 150 W a 12 V / 300 W a 24 V
Assorbimento / Absorption max 12,5 A
Input DMX 512 o pulsanti / DMX 512 or push-buttons
Segnale di controllo per QCC-DRV 4CH
Output
Quick color control control signal for QCC-DRV 4CH
Pilot 300 Watt Cortocircuito / Short circuit / Surriscaldamento / Overheating
Protezioni / Protections
Dispositivo di gestione del sistema QCC Sovraccarico / Overload / Picchi di tensione / Voltage spikes
QCC system management device Dimensioni (L x A x P) / Dimensions (W x H x D) 87,5 x 112 x 58 mm (3 7 /16 x 4 13 /32 x 2 9 /32 inch)

QCC-DRV 4CH [ IP20 SELV ]

Modello / Model QCC-DRV 4CH
Input Segnale di controllo da QCC-PLT 300 / Control signal for QCC-PLT 300
Corrente costante 350mA max per ogni colore,
per pilotare i faretti QCC RGBW
Output
350 mA max constant current for each colour, ELECTRONIC ACCESSORIES
to drive the QCC RGBW downlights
Quick color control
Driver 4 channels Protezioni / Protections Cortocircuito / Short circuit / Surriscaldamento / Overheating
Sovraccarico / Overload / Picchi di tensione / Voltage spikes
Driver per faretti RGBW o luce dinamica
RGBW or tunable white (TW) downlights driver Dimensioni (L x A x P) / Dimensions (W x H x D) 66,5 x 59 x 27,4 mm (2 5 /8 x 2 21 /64 x 1 5 /64 inch)

QCC-DRV 4CV [ IP20 SELV ]

Modello / Model QCC-DRV 4CV
Input Segnale di controllo da QCC-PLT 300 / Control signal for QCC-PLT 300
Tensione costante - Max 2,5A
per pilotare la QCC STRIP LED RGBW
Output
Constant voltage - Max 2,5A
to drive the QCC STRIP LED RGBW
Quick color control Cortocircuito / Short circuit / Surriscaldamento / Overheating
Driver 4 channels Protezioni / Protections
Sovraccarico / Overload / Picchi di tensione / Voltage spikes
Driver per Strip LED RGBW o luce dinamica Dimensioni (L x A x P) / Dimensions (W x H x D) 66,5 x 59 x 27,4 mm (2 5 /8 x 2 21 /64 x 1 5 /64 inch)
RGBW or tunable white (TW) Strip LED driver
