Page 49 - Quick

LUCI LED DA INCASSO / LED DOWNLIGHTS

VIP NICE SERIES

TED VN - 4W - IP66 CRI WARM WHITE
90
TED VN - 4W - IP66 Ø 54 (2 1/8)
Fissaggio con viti / Screw installation
Ø Cornice / Ø Bezel 72 mm
Recesso / Recess 20,5 mm 20,5 (13/16)
5 (13/64)
Ø Foratura / Ø Cutout 54 mm
Ø 72 (2 53/64)
4W + Courtesy light

EDWIN VN- 4W - IP66 CRI WARM WHITE
90
EDWIN VN - 4W - IP66 Ø 54 (2 1/8)
Fissaggio con viti / Screw installation
Lato cornice / Side bezel 72 mm
Recesso / Recess 20,5 mm 20,5 (13/16)
5 (13/64)
Ø Foratura / Ø Cutout 54 mm
72 (2 53/64)
4W + Courtesy light

BRYAN VN - 4W - IP66 CRI WARM WHITE
90
BRYAN VN - 4W - IP66 Ø 54 (2 1/8) LED RECESSED DOWNLIGHTS
Fissaggio con viti / Screw installation
Lato cornice / Side bezel 72 mm
Recesso / Recess 20,5 mm 20,5 (13/16)
5 (13/64)
Ø Foratura / Ø Cutout 54 mm
72 (2 53/64)
4W + Courtesy light

Dimensioni / Dimensions - mm (inch)

Quick Marine Lighting - Edition 12 49
