WIPER C ONTROL S

C ONTROL S

Full-featured electronic control panels.

CP4EX Control Panel
• Electronic control for two, three, four and five 12v
or 24v wiper motors
• Consists of dashboard panel, separate relay box and
plug-and-play connecting cable
• Five operating speeds: low, high, 3 intermittent levels
• Synchronized wiping at each operating speed
• Smart wipe-wash program
• ON/OFF switch
• Individual switches for each wiper
• Heater switch
• Single sweep button
• Back light dimmer (three level brightness)
• LED indicators to indicate speed setting CP4EX Series Control
• Option to network multiple wipers within individual zones
Dimensions
• Panel: 4” H x 3.875” W x 1.5” D (100 x 98 x 39mm)
• Relay box: 7.52” L x 4.29” W x 1.57” H (191 x 109 x 40mm)

210 Series Control Panel
• Electronic control for two, three, four and five 12V
or 24V wiper motors
• Consists of dashboard panel, separate relay box and
plug-and-play connecting cable
• Five operating speeds: low, high, 3 intermittent levels 210 Series Control
(with 2.5-second, 5-second, 10-second delay)
• Synchronized wiping at each operating speed
• Smart wipe-wash program
• ON/OFF switch SMART WIPE-WASH
• Individual switches for each wiper
• Indicator lights for active wipers, speed/intermittent Controls that feature a Smart Wipe-Wash Program are
settings and wipe-wash able to clear your windshield with a single touch of a
• Low-fluid warning LED for washing system (requires tank sensor) button. The smart function starts the spray of washing
• Option to network multiple wipers within individual zones fluid (or water from ship’s supply), adjusts the
• Option for dimming available operating speed of the motors to continuous low
Dimensions speed, continues wiping for a few seconds after the
• Panel: 4" H x 3.875" W x 3" D (100 x 98 x 75mm) spray stops, and then returns to the speed that was
• Relay box: 7.52" L x 4.29" W x 1.57" H (191 x 109 x 40mm) in effect before the washing cycle was initiated.
• Connecting cable: 5 meter connecting cable between Some of our controls allow the smart function to be
panel and control customized by the operator.
