C ONTROL S

C ONTROL S

Simple switches or full-featured electronic control options.

CT3EX Wiper Control
• Electronic control for a maximum of three 12V or
24V wiper motors
• Consists of dashboard panel, separate relay box and
plug-and-play connecting cable
• Five operating speeds: low, high, 3 intermittent levels
(with 2-second, 4-second, 8-second delay)
• Synchronized wiping at each operating speed
• Smart wipe-wash program
• ON/OFF switch
• Individual switches for each wiper
• Indicator lights for active wipers, speed/intermittent
settings and wipe-wash
• Warning system indicates a failing wiper or incorrect wiring
• Optional dual-station version available CT3EX Wiper Control
Dimensions
• Panel: 2.875" H x 2.875" W x 2.56" D (72 x 72 x 65mm)
• Relay box: 3.125" L x 2.187" W x 1.375" H (80 x 55 x 35mm)
• Connecting cable: 8'2" with plug

Quad Control Panel
• Control panel for up to four 12V or 24V wiper motors
• Four operating speeds: low, high, 2 intermittent levels
(with 5-second and 10-second delay)
• Synchronized wiping at each operating speed
• Smart wipe-wash program
• UV-safe ABS plastic
• Turn wiper groups on/off independently or together
• Self-parks all wipers
• Includes integral 15A fuse (no inline fuses required)
Dimensions
Quad Control Panel
• 3.5" H x 3.5" W x 2.375" D (90 x 90 x 61mm)

CT41/42 Electronic Wiper Switches
• Electronic switches for standard dashboard systems
(such as Carlingswitch®)
• Available in one-wiper model (CT41) and two-wiper
model (CT42)
• Five operating speeds: low, high, 3 intermittent levels
(with 2-second, 4-second and 8-second delay)
• Multi-function switch for one or two wipers (10-30VDC)
• Smart wipe-wash program
• CT42 operates both wipers synchronized or independently CT41/42 Electronic Wiper Switch
• Contact Imtra for high amp options
