C ONTROL S

RC532 Series Electronic Wiper Switches
• Electronic switches that combine a remote-mounted
electronic box and a single, momentary Carlingswitch
to control all functions for three wiper motors
• Compatible with 12V or 24V motors
• Separate models for W10/W12, W25/W38, and W50 series
• Three operating speeds: low, high, intermittent
• Allows operation of a single primary wiper or synchronized
operation of up to three wipers
• Compatible with 12V or 24V motors
• Operates wash solenoid or pump
• Illuminated Carlingswitch rocker switch and 3' (1m)
connecting harness included RC532 Series Electronic Wiper Switch and Control Boxes

Simple Rotary Switch
• Simple 2-speed rotary switch
• Compatible with 12V or 24V motors
• Dynamic park or coast to park
• Includes option for wash functionality
Simple Rotary Switch

Simple Rocker Switch
• Simple 2-speed rotary switch
• Compatible with 12/24V motors
• Dynamic park or coast to park

W10/W12 Simple Rocker Switch W25/W38/W50 Simple Rocker Switch

Combination Rotary Switch
• 12V or 24V available
• Variable intermittent time delay
• Continuous low and high speed
• Push-button wash function
• Dynamic park or coast to park Combination Rotary Switch
Optional cover plate available - Imtra or Exalto branded
