LUCI LED DA INCASSO / LED DOWNLIGHTS

MARINA XP SERIES

MARINA XP FP - 4W CRI WARM WHITE
90
NEW
MARINA XP FP - 4W - IP66 Ø 65 (2 9/16)
Fissaggio a molle / Spring installation
Lato cornice / Side bezel 79 mm
Recesso / Recess 30 mm
Ø Foratura / Ø Cutout 65 mm 30 (1 3/16)

4W + Courtesy light 1,5 (1/16) 79 (3 7/64)

MARINA XP LP - 4W CRI WARM WHITE
90
MARINA XP LP - 4W - IP66 Ø 65 (2 9/16)
Fissaggio a molle / Spring installation
Lato cornice / Side bezel 79 mm
Recesso / Recess 30 mm
Ø Foratura / Ø Cutout 65 mm 30 (1 3/16)

4W + Courtesy light 2 (5/64)
79 (3 7/64)

CRI
MARINA XP HP - 4W MARINA XP HP - 4W - IP66 WARM WHITE Ø 65 (2 9/16)
90
LED RECESSED DOWNLIGHTS MARINA XP FP - 6W Lato cornice / Side bezel WARM WHITE 4 (5/32) 79 (3 7/64) 28 (1 7/64)
Fissaggio con viti / Screw installation
79 mm
28 mm
Recesso / Recess
65 mm
Ø Foratura / Ø Cutout

4W + Courtesy light

CRI
90
MARINA XP FP - 6W - IP66
NEW
Fissaggio a molle / Spring installation
Lato cornice / Side bezel
Recesso / Recess 79 mm Ø 65 (2 9/16)
30 mm
Ø Foratura / Ø Cutout 65 mm 30 (1 3/16)

6W + Courtesy light 1,5 (1/16)
MARINA XP FP RGBW - 6W - IP66 79 (3 7/64)
MARINA XP FP TW - 6W - IP66
MARINA XP LP - 6W CRI WARM WHITE
90
MARINA XP LP - 6W - IP66
Fissaggio a molle / Spring installation Ø 65 (2 9/16)
Lato cornice / Side bezel 79 mm
Recesso / Recess 30 mm
Ø Foratura / Ø Cutout 65 mm 30 (1 3/16)

6W + Courtesy light 2 (5/64)
MARINA XP LP RGBW - 6W - IP66 79 (3 7/64)
MARINA XP LP TW - 6W - IP66

MARINA XP HP - 6W CRI WARM WHITE
90
MARINA XP HP - 6W - IP66
Fissaggio con viti / Screw installation Ø 65 (2 9/16)
Lato cornice / Side bezel 79 mm
Recesso / Recess 28 mm
Ø Foratura / Ø Cutout 65 mm 28 (1 7/64)

6W + Courtesy light 4 (5/32)
MARINA XP HP RGBW - 6W - IP66
MARINA XP HP TW - 6W - IP66 79 (3 7/64)
Dimensioni / Dimensions - mm (inch)
