REFERENCE CHAR T S

WIPER MOTORS Voltage Bulkhead Thickness Item #
0.625" (16mm) RC525991
W10 Series 12V 1.625" (41mm) RC524991
2.625" (66mm) RC525891
0.625" (16mm) RC525992
24V 1.625" (41mm) RC524992
2.625" (66mm) RC525892
0.625" (16mm) RC533011 (white) RC533511 (black)
W12 Series
12V 1.625" (41mm) RC533021 (white) RC533521 (black)
2.625" (66mm) RC533031 (white)
0.625" (16mm) RC533012 (white) RC533512 (black)
24V 1.625" (41mm) RC533022 (white) RC533522 (black)
2.625" (66mm) RC533032 (white)
1.1" (28mm) RC531015
W25 Series
12V 2.1" (53mm) RC531025
3.1" (78mm) RC531035
1.1" (28mm) RC531016
24V 2.1" (53mm) RC531026
3.1" (78mm) RC531036
1.1" (28mm) RC531011
W38 Series
12V 2.1" (53mm) RC531021
3.1" (78mm) RC531031
1.1" (28mm) RC531012
24V 2.1" (53mm) RC531022
3.1" (78mm) RC531032
1.1" (28mm) RC531013
W50 Series
12V 2.1" (53mm) RC531023
3.1" (78mm) RC531033
1.1" (28mm) RC531014
24V 2.1" (53mm) RC531024
3.1" (78mm) RC531034

WIPER ARMS Length Description Item # Washing Jet
W10/W12 Series (Pendulum) 12.8"–18" (324-460mm) Fixed Spring, Electro-Polished, Adj. Tip RC536218
18"–23.3" (545-591mm) Fixed Spring, Electro-Polished, Adj. Tip RC536224
12.8"–18" (324-460mm) Fixed Spring, Black, Adj. Tip RC538218
18"–23.3" (454-591mm) Fixed Spring, Black, Adj. Tip RC538224 EX21000.326
12.8"–18" (324-460mm) Dual Springs, Electro-Polished, Fixed Tip RC536318
W10/W12 Series (Pantograph)
18"–23.3" (454-591mm) Dual Springs, Electro-Polished, Fixed Tip RC536324
12.8"–18" (324-460mm) Dual Springs, Black, Fixed Tip RC538318
18"–23.3" (454-591mm) Dual Springs, Black, Fixed Tip RC538324
W10/W12 Series Heavy Duty (Pantograph)
12"–23.6" (305-600mm) Fixed Spring, Black, Fixed Tip EX2108K EX2184

W25 Series (Pendulum) 18.5"–29.5" (470-750mm) Fixed Spring, Black, Adj. Tip, w/Wash Jet RC538230
18.5"–29.5" (470-750mm) Fixed Spring, SS, Adj. Tip, w/Wash Jet RC536230

W25 Series (Pantograph) 18.5"–29.5" (470-750mm) Fixed Spring, Black, Fixed Tip, w/Wash Jet RC538330
18.5"–29.5" (470-750mm) Fixed Spring, SS, Fixed Tip, w/Wash Jet RC536330
RC531135
W38 Series (Pantograph) 24.4"–35.4" (620-900mm) Fixed Spring, Black, Fixed Tip, w/Wash Jet RC536335
24.4"–35.4" (620-900mm) Fixed Spring, SS, Fixed Tip, w/Wash Jet RC538335
18.5"–29.5" (470-750mm) RC536430
18.5"–29.5" (470-750mm) RC538430
W50 Series (Pantograph) 40"–47" (1020-1200mm) Fixed Spring, Black, Fixed Tip, w/Wash Jet RC536347
40"–47" (1020-1200mm) Fixed Spring, SS, Fixed Tip, w/Wash Jet RC538347
