QUES TIONNAIRE

CONTACT INFORMATION
A

Name
Company
E
Address
IMTRA COLORS 2016
Primary Use City Secondary Use State ZIP
C
Tel Fax
Email
Blue Pantone 647 Pantone Cool Gray 7 Pantone Cool Gray 2 Black Pantone 368 Pantone 629
96C 54M 5Y 27K 20C 14M 12Y 40K Owner’s Name 0C 0M 0Y 100K 65C 0M 100Y 0K 36C 0M 9Y 0K D
5C 3M 5Y 11K
Project Name B
Type of Application
Motor Voltage & Location
Window Type
q
12VDC
q
24VDC
WA WB WC WD WE WF q
Below Window
q
Above Window
External
NOTE: Straight Line Wiper Systems are available. Please note window height and width in the comment q
field below for recommendations.
WINDOW DIMENSIONS Switchgear Selection
Electronic Control Panel (Synchronized)
Port/ Starboard/ q
Port Center Center Center Starboard q
Electronic Wiper Switch (Synchronized)
q
Individual Switch with Intermittent
Window Type (see above)
q
Individual Switch without Intermittent
Window Height (C) q
No Switchgear Needed
Width of Glass/Top (A)
Washing System Details
Width of Glass/Bottom (B)
q
Complete System from Ship’s Supply
Motor Setback* from Window (D)
q
Complete System from Reservoir
Bulkhead Mounted Jet
Eye Level (E) q
q
Arm Mounted Jet
Bulkhead Thickness
q
No System Required
*The distance between the inside edge of the windshield frame and the center of the motor shaft
Please take into account the radius of any corner when measuring window dimensions.
q
Please check if wiper motor mounting position is not parallel with windshield. If known, what is the angle
between them? _______
Comments:
