INTRODUC TION
WIPER S Y S TEM O VER VIEW
What you need to know before installing a wiper system
The importance of a quality wiper system is often overlooked – until you need it most. When visibility is poor and
conditions are rough, a durable, fully-functional wiper system can make all the difference. Imtra can help you select
the right equipment to satisfy all of your requirements. When evaluating a new wiper system, there are a number of
factors to consider:
Window Size Motor Mounting Location
While application is taken into account, the determining factor With each system, we strive to maximize the area of the
in choosing a wiper system is the size and shape of the glass to be windshield that will be cleared. However the most important
cleaned. The larger the windshield, the longer the wiper arms and area to clean is where the operator is most likely to be looking
In Line Wiper
blades need to be. Since longer arms and blades create more through; often this dictates the mounting location of the motor.
friction, you will also need a stronger motor. The best solution for Installation ease and service accessibility should be taken into
taller and broader windshields would be a larger wiper system consideration when choosing the location, and in some cases
capable of driving those longer arms and blades. exterior styling can be an additional factor.
Wiper motors are usually fitted either directly below or above
the window and equipment is available to mount the motor on
the interior or the exterior depending on the application.
Wiper Type
We offer a variety of wiper types to meet customer
SIZING KEY
requirements whether that be to maximize wiped area, simplify
Each wiper system is sized based on the maximum installation or to achieve a clean and unobtrusive position when
Pantograph Wiper the wipers are idle. If you have any questions about which
arm and blade length. From these values we can
determine the maximum reach and can generalize system is right for you, please contact IMTRA for assistance.
a size of the window. Use the icons featured on the
coming pages to direct you to the right wiper
system choice.
Pendulum Wiper Pantograph Wiper
A sweep pattern in which the blade stays parallel to the side of
the glass. Pantograph wipers are typically used on windows that
are taller than wide.
6
www.imtra.com
Linked System
