P. 131
Cleats
Streamline Closed Base Cleat
Material: Zinc Alloy
Finish: Chrome Plated
Length Dimensions Max. Rope Screw
Overall Base Size Retail Pkg.* Size Fig. 0566
2” 2-3/16” x 1-1/8” 5/16” 0566DP2CHR 6
3” 3-1/8” x 1-1/2” 3/8” 0566DP3CHR 8
4-1/2” 4-7/16” x 1-7/8” 1/2” 0566DP4CHR 10
*Sold in pairs. Deck and Cabinet Hardware, Hinges, Locks & Latches
Open Base Cleat
Material: Zinc Alloy
Finish: Chrome Plated
Dimensions: Overall Length: 6-1/2”
Base: 3” x 1-1/8”
Screw Size: 1/4”
Max. Rope Size: 3/4”
8
Retail Pkg.* OEM Bulk Pkg. Fig. 1252
1252DP0CHR 1252000CHR
*Sold in pairs.
Open Base Cleat
Material: Aluminum
Finish: Plain
Length Dimensions Max. Rope Screw Fig. 0530
Overall Base Size Standard Pkg. Size
8” 4 x 2”-1/4” 3/4” 0530008ALU 1/2”
10” 4-1/2” x 3” 7/8” 0530010ALU 1/2”
12” 6-1/2” x 2-7/8” 1” 0530012ALU 5/8”
15” 7” x 3-1/4” 1-1/2” 0530015ALU 3/4”
®
Visit www.perko.com for installation instructions and technical drawings on most PERKO products. 131
