EX AL T O WIPER S Y S TEMS

T YPE 2 SERIES

The ultimate system for windows up to 65" (1650mm) in height.

Type 2 Series Motors
• Two bulkhead thicknesses: 1.375" (35mm), 2.5" (65mm)
• Dynamically parks (right or left)
• 316 stainless steel 0.75" (20mm) drive and support shaft
• Tapered drive shaft for secure arm/motor connection
• Dual drive shafts
• Custom bulkhead thickness available

255BS Wiper Motor
EX2115.55
255BS Wiper Covers
MO T OR SPECIFICA TIONS
Models
Sweep angle adjustment Stepless
o
Sweep angle range 40 - 90 o
Voltages 12V and 24V
Amp draw 2.5A (12V); 1.3A (24V)
Fuse size – slow-blow 8A (12V); 6A (24V) 25mm/0.98in
60mm/2.36in
Torque 55Nm
Sweeps per minute 38 (low); 60 (high)
Max arm length 37.75" (1000mm) MAX 142.5mm/5.61in
42mm/1.65in
Max blade length 47.25" (1200mm)
250mm/9.84in

L = BULKHEAD
THICKNESS
CUSTOM APPLICATIONS AS LISTED
In addition to the standard motors featured in this
catalog, many of our motors can be special-ordered
with custom bulkhead thicknesses to fit unusual L 79mm/3.11in 47.7mm/1.88in
mounting arrangements. We also offer a solution for
explosion proof applications. Contact Imtra if you have
a unique application, and we will work with you to
develop a wiper solution to meet your requirements.
