EX AL T O WIPER S Y S TEMS

Type 2 Series Arms
• Fits 255BS motor
• 316 stainless steel components with brass attachment heads
• Adjustable-length wiper arms
• Offered in two versions (“S” and “B”) to fit blades of different Type 2 arms are drilled
lengths and widths to run washing system
tubing conveniently
• Arms can be folded back for cleaning inside the arm.
• 10mm box section arm extensions with channel for washing
system tubing Two different washing jet
options are available on
• Optional arm-mounted washing jets (see insets) Type 2 arms:

Type 2 Series Blades
• Standard and heavy duty blades available
• 24", 25.5", 27.5", 29.5", 31.5", 33.5", 35.5", 37.5", 39.5" and 47.25" Washing Jet Option 1
lengths for Type 2 applications Our EX2185 (or left-handed
• Durable stainless steel upper-bridges with high-impact polymer EX2185L) snaps easily into
the standard blade clip.
lower-bridges for optimal blade/glass contact Each jet features four
adjustable nozzles.
When using both jets,
Replacement Blade Inserts fluid is applied to both
sides of the blade.
• Available in 39" and 47.25" lengths (can be cut to fit shorter blades)
• With extra clips, one longer insert can be cut to replace two
shorter blades

ARM & BLADE SPECIFICA TIONS
Washing Jet Option 2
Type “S” Type Arms “B” Type Arms The EX2111 mounts under
the blade clip and extends
Pantograph arm length range 29.5-39.4" (750-1000mm) so fluid is applied from six
Finish Black nozzles (three on each side
of the blade).
Arm length type Adjustable
Accepted blade length 19.7-31.5" (500-800mm) 33.5-47.25" (850-1200mm)
Dual Spring Fixed or Adjustable
Blade attachment method 5mm Bolt 8mm Bolt
Blade clip width .5" (12mm) .75" (20mm) Type 2 arms adjust easily
Washing jet Optional and securely to the
optimum length for each
installation.

Galleries feature 316
stainless steel construction,
Type 2 Wiper Arm brass heads and protective
head covers.

MAX 65"
1650
mm
