Fuel Tank Vents

90° Angled Tank Vent with Swivel Elbow
Angled Design Allows Elbow to be Rotated to any Position USABLE WITH EPA COMPLIANT
FUEL SYSTEMS
Material: Zinc Alloy Elbow, Polymer Splash Guard
Finish: Black or White Splash Guard Fig. 0592
For Vent Hose: 5/8” Style 2
Max. Hull Thickness: 5/8”
Features: • Three Styles of Splash Guards
• Removable 30 Mesh Stainless Steel Wire
Screen Flame Arrestor (for use with
gasoline applications)

Fig. 0592
Fig. 0592
Style 1
Splash Splash Style 3
Guard Style Guard OEM Bulk Pkg.
Style 1 Black 0592014BLK
Style 1 White 0592014WHT Three Splash Guard Styles Available in Black or White
Style 2 Black 0592024BLK
Style 2 White 0592024WHT
Style 3 Black 0592034BLK
Style 3 White 0592034WHT

Individual Splash Guard Spare Part Ordering Information
Style 1: Black - Cat. No. 0592B1099A, White - Cat. No. 0592W1099A,
Style 2: Black - Cat. No. 0592B2099A, White - Cat. No. 0592W2099A.
7 Style 3: Black - Cat. No. 0592B3099A, White - Cat. No. 0592W3099A. Style 1 Mounted Style 2 Mounted Style 3 Mounted

Straight or 90° Angled Tank Vent with Swivel Elbow
Deck Plates, Fills, Tank Vents, and Ventilators
Angled Design Allows Elbow to be Rotated to any Position
Material: Zinc Alloy Elbow, Stainless Steel USABLE WITH EPA COMPLIANT
FUEL SYSTEMS
Escutcheons with Polymer Splash Guard
Finish: Black or White Splash Guard
Fig. 0597: Chrome Plated Straight Body
Fig. 0598: Plain 90° Elbow Body

For Vent Hose: 5/8”
Max. Hull Thickness: 5/8”
Fig. 0597
Features: Removable 30 Mesh Stainless Steel Wire
Screen Flame Arrestor (for use with
gasoline applications)

Splash
Style Guard Retail Pkg. OEM Bulk Pkg.
Straight Black 0597DP4BLK 0597004BLK
Straight White 0597DP4WHT 0597004WHT
90° Angle Black 0598DP4BLK 0598004BLK
90° Angle White 0598DP4WHT 0598004WHT Fig. 0598

Spare Splash Guard Cap: Black, Cat. No. 0570B0099A, White, Cat. No. 0570W0099A

Note: All of the Above Vents are Designed to Meet the Requirements of
U.S.C.G. Safety Standards January 31, 1977, for Gasoline Fuel Systems 33 CFR 183.

110 Visit www.perko.com for installation instructions and technical drawings on most PERKO products.
®
