Non-EPA Vented and Non-Vented Deck Fills for 1-1/2” Hose with Resin Insert

Gas, Diesel, Water and Waste Deck Fills
Patent Nos. 5,275,213 & 5,327,946
Material: Scalloped Bronze or Stainless Steel Cap, Resin Insert,
Polymer Body and Tether
Finish: Chrome Plated or Polished Cap with Black Body and Tether
Fill Hose Size: 1-1/2”
Vent Hose Size: 5/8”
Ground Wire: Not Required
Mounting Hole Dia: 2-1/8” Fig. 0582 Gas
O.D. Flange: 3-3/8” Shown
Screw Size: #8
Neck Length: Vented Fills: 2-7/16”
Non-Vented Fill: 3-1/8”
Features: • Integral Tank Vent with Anti Surge Valve
• Flame Arrestor (on gas and diesel only)
• Deck Plate Key Not Required
• Color Coded Resin Inserts for Gas, Diesel,
Water and Waste
Fig. 0582: Angled Neck, Vented Gas, Diesel, or Water Fill
Fig. 0583: Straight Neck, Vented Gas, Diesel, or Water Fill
Fig. 0552: Straight Neck, Non-Vented Gas, Diesel, or Water Fill
Fig. 0569: Straight Neck, Non-Vented Waste Fill
Chrome Stainless
Type Neck OEM Bulk Pkg. OEM Bulk Pkg. Retail Pkg. Color Coded Resin Inserts
Vented
2
Gas Angled 0582G00CHR 1 0582G00STS 1 0582DP0CHR 1
2
Diesel Angled 0582D00CHR 0582D00STS (Angled Fill, Chrome Cap
Water Angled 0582W00CHR 0582W00STS with 3 Inserts)
7
2
Gas Straight 0583G00CHR 1 0583G00STS 1 0583DP0CHR 1
2
Diesel Straight 0583D00CHR 0583D00STS (Straight Fill, Chrome Cap
Water Straight 0583W00CHR 0583W00STS with 3 Inserts)
Non-Vented
Gas Straight 0552G00CHR 1 0552G00STS 1 0552DP0CHR 1
2
2
Diesel Straight 0552D00CHR 0552D00STS (Non-Vented Fill, Chrome Cap
Water Straight 0552W00CHR 0552W00STS with 4 Inserts) Fig. 0540DPRBLK 2
3
Waste Straight 0569000CHR 0569000STS Mounting Ring
Non-Vented Style Fills
Vented Style Fills

Fig. 0583 Gas, Diesel, or Water Options Fig. 0552 Gas, Diesel, or Water Options Deck Plates, Fills, Tank Vents, and Ventilators
Fig. 0569
Waste 3
Note: Retail Pkg for vented fills includes fill, cap and 3 inserts (Gas, Diesel, Note: Retail Pkg for non-vented fills includes fill, cap and 4 inserts (Gas, Diesel,
& Water). Use Gas insert on fill only with Non-EPA Compliant fuel systems. Water, & Waste). Use Gas insert on fill only with Non-EPA Compliant fuel systems.
1 NOTE: These Items Meet the Requirements of U.S.C.G. Safety Standards, January 31, 1977, for Gasoline Fuel Systems, 33 CFR 183.
Fills shown on this page DO NOT meet the requirements for 40 CFR 1060 sub part B Emissions Standards and Related Requirements.
Spare Parts Ordering Information 2 Note: Consider using the Mounting Ring for all installations.
Cap for Vented Fills: Cap, O-Ring & Retainer: 0582DPC99A Retail package includes mounting ring. See Page 122
(Includes 3 Resin inserts: Gas, Diesel & Water)
Cap for Non-Vented Fills: 0552DPC99A (incl. 4 inserts) 3 NOTE: Fig. 0569 Complies with Adopted Standards on “Fittings”
Resin Insert Kit: 0030DP0004 (includes 4 inserts: Gas, Diesel, A.B.Y.C. Recommended Practices Standards Covering Sewage
Water, & Waste) Holding and/or Treatment Devices for Marine Waste Systems.

®
Visit www.perko.com for installation instructions and technical drawings on most PERKO products. 115
