Flush Locks & Latches

Surface Mount Flush Locks and Latches Fig.
Material: Polymer Body with Zinc Alloy Handle and Stainless Steel 0931 #1
Stem and Lock Nut
Finish: Black or White Body with Chrome Plated Handle
Dimensions Face Plate: 2-1/2” x 2-1/2”
For Door Thickness: 1/4” to 1-1/8”
Deck and Cabinet Hardware, Hinges, Locks & Latches
Installation: Mounting Hole Diameter: 2”
Features: • Detents indicate open or closed position.
• Size No. 1: Offset cam bar and flexible polymer strike
• Size No. 2: Offset adjustable cam bar
• Size No. 3: Straight cam bar and flexible polymer strike Flexible
Fig. 0931: Lock with 2 keys Polymer
Fig. 0932: Latch, non-locking Strike
Adjustment Black White Black White
Type Cam Bar Retail Pkg. Retail Pkg. OEM Bulk Pkg. OEM Bulk Pkg.
Lock 3/8” to 3” 0931DP1BLK 0931DP1WHT 0931001BLK 0931001WHT
Lock 3/8” to 3” 0931DP2BLK 0931DP2WHT 0931002BLK 0931002WHT
Lock 1-1/16” to 2-9/16” 0931DP3BLK 0931DP3WHT 0931003BLK 0931003WHT
Latch 3/8” to 3” 0932DP1BLK 0932DP1WHT 0932001BLK 0932001WHT
Latch 3/8” to 3” 0932DP2BLK 0932DP2WHT 0932002BLK 0932002WHT Fig. 0932 #2 Fig. 0931 #3
Latch 1-1/16” to 2-9/16” 0932DP3BLK 0932DP3WHT 0932003BLK 0932003WHT
Spare Parts Ordering Information
Offset Cam Bar: 093100199A Offset Adjustable Cam Bar: 093100299A
Straight Cam Bar: 093100399A Flexible Polymer Strike: 093100099B
Surface Mount Flush Locks and Latches
Material: Polymer Body with Zinc Alloy Handle and Stainless Steel
Fig. 1031
Stem and Lock Nut
Finish: Black or White Body with Chrome Plated Handle
Dimensions Face Plate: 3-1/8” x 3-1/8”
For Door Thickness: 1/8” to 3/4”
8 Installation: • Flush mounts in a 2-3/8” x 2-3/8” hole
• Surface mounts in a 1-5/8” diameter hole
with polymer spacer (included)
Features: • Large handle allows two finger grip
Fig. 1031: Lock with 2 keys
Fig. 1032: Latch, non-locking

Adjustment Black White Black White
Type Cam Bar Retail Pkg. Retail Pkg. OEM Bulk Pkg. OEM Bulk Pkg.
Lock 1/2” to 3” 1031DP1BLK 1031DP1WHT 1031001BLK 1031001WHT Fig. 1032
Latch 1/2” to 3” 1032DP1BLK 1032DP1WHT 1032001BLK 1032001WHT

Spare Parts Ordering Information
Offset Cam Bar For 1031/1032: 103100499A

Lock and Latch Cover
Material: Fiber Reinforced Polymer
Finish: Black or White
Features: Hinged, water resistant

Overall
Color Fits Fig. No. Dimensions Retail Pkg. OEM Bulk Pkg.
Black 0931/0932 2-3/4” x 3-1/4” 1089DP1BLK 1089001BLK
White 0931/0932 2-3/4” x 3-1/4” 1089DP1WHT 1089001WHT
Black 1031/1032 3-1/4” x 3-3/4” 1089DP3BLK 1089003BLK
White 1031/1032 3-1/4” x 3-3/4” 1089DP3WHT 1089003WHT Fig. 1089

158 Visit www.perko.com for installation instructions and technical drawings on most PERKO products.
®
